同用的规模该设备根本中用各个纸制品包装机，纸塑复合型类，膜类等装潢文件和包装机文件的复卷。

后能及独特的 1.该设备接纳孩子伺服电机定长送料机，在迅速进行中追求高表面粗糙度。2.PLC触屏屏积极计米，米数积极场景人物风格的设定在。3.气动弹簧式自主上料机，收、放魔石配气胀轴。4.主动性切段、智泊那时候单独场景人物风格的设定在，预送推算收秘药再延续收料等保健作用。Scope of applicationScope of applicationThis machine is mainly used for re-winding of various paper, paper-plastic composite, film and other decorative materials and packaging materials.

Performance and characteristics1. This machine adopts servo fixed length feeding to maintain high precision during high speed operation.2. PLC touch screen automatically counts meters, meters are automatically set.3. Pneumatic automatic feeding, receiving and discharging reels with air expansion shaft.4. Automatic cutting, free parking time setting, pre-feeding to rewind and continue to receive materials.

首要手艺参数 Main Technical Parameters

型号(hao) Model		CLFJ-B800	CLFJ- B1000	CLFJ-B1300
板料净宽 MAX.Parent Web Width		800mm	1000mm	1300mm
放卷直径怎(zen)么算(suan) Max.parent Web Diameter		Φ600mm	Φ600mm	Φ600mm
收卷长度 Max.Rewinding Diameter		Φ300mm	Φ300mm	Φ300mm
频率 Max.Machine Speed		10-180m/min	10-180m/min	10-180m/min
定长(zhang)精度(du)等(deng)级(ji)Fixed length accuracy		±5mm	±5mm	±5mm
总输出 Total Power		2.3KW	3KW	4.5KW
信噪比 Machine Weight		1000kg	1200kg	1500kg
形状图片(pian)大全(quan)图片(pian)尺寸 Over🤪all Dimensions 重(zhong)任电(dian)流电(dian)压(ya) Working Voltage		2600×2000×1600mm 二相220V50HZ	2600×2200×1600mm 二相(xiang)220V50HZ	2600×2500×1600mm 三(san)相380V50HZ
纸芯(xin)规格型号Paper core specification	25mm, 38mm,50mm等 (or according to your requirement)
