重在手艺活参数指标 Main Technical Parameters

机型 Model	CLFJ-B1000	CLFJ- B1300	CLFJ-B1600
卷材宽度 MAX.Parent Web Width	1000mm	1300mm	1500mm
放卷直径 Max.parent Web Diameter	Φ800mm	Φ800mm	Φ800mm
收卷直径 Max.Rewinding Diameter	Φ300mm	Φ300mm	Φ300mm
速率 Max.Machine Speed	10-150m/min	10-150m/min	10-150m/min
定长精度 Fixed length accuracy	±5mm	±5mm	±5mm
总功率 Total Power	3KW	3.5KW	4.5KW
分量 Machine Weight	1000kg	1200kg	1500kg
形状尺寸 Overall Dimensions 任务电压 Working Voltage	2600×2000×1600mm      二相220V50HZ	2600×2200×1600mm      二(er)相(xiang)220V50HZ	2600×2500×1600mm      三相380V50HZ
纸芯规格 Paper core specification	25mm, 38mm,50mm等 (or according to your requirement)

好用占比终端服务器根本用以特殊纸品，纸塑混合类，膜类等装潢档案信息和再生档案信息的复卷修边分割。

卡能及上海特色 1.超声波焊接机进行伺服电机定长送料机，在迅速正常运行中坚持什么高可靠性强，精密度。2.PLC触碰屏分手后的计米，米数分手后的添加。3.圆刀/直刀纵切废边自主的尾气排放标准装配图。4.气动式式分手后装料，收、放法杖配气胀轴。5.分手后断掉、驻车期间自得设制，预送预测收法杖再不断收料等作用与功效。

Scope of application

This machine is mainly used for re-windi🍸ng and trimming of various papers, paper-plastic composites, 🍰film and other decorative materials as well as packaging materials.

Performance and characteristics

1. This machine adop൩ts servo fixed length feeding to maintain h🐼igh precision during high speed operation.

2. PLC touch screen automatically counts meters, meters are 𝓀automatica👍lly set.

3. Round knife / straight knife slitting automatic waste disᩚᩚᩚᩚᩚᩚ⁤⁤⁤⁤ᩚ⁤⁤⁤⁤ᩚ⁤⁤⁤⁤ᩚ𒀱ᩚᩚᩚcharge devi☂ce.

4. Pneumatic automatic feeding, receiving💦 and discharging reels with air expansion shaft.

5. Automatic cutting, free parking time setting, pre-feeding to rewind and continue to receive ⛄materials.
